APC Easy UPS On-Line SRV - 10kVA Rackmount 5U, Extended Runtime
APC Easy UPS On-Line SRV adalah UPS on-line berkapasitas 10000 VA (10000 W) dengan bentuk Rackmount 5U, gelombang keluaran Sine wave serta stopkontak keluaran Hard wire 3-wire (1P + N + E) for 1 zone(s).
Dijual oleh
Yolori Mall
APC Easy UPS On-Line SRV adalah UPS on-line berkapasitas 10000 VA dengan daya keluaran 10000 W. Bentuk gelombang keluarannya Sine wave. Tegangan keluarannya 230 V AC 1 phase dengan frekuensi 50/60 Hz +/- 3 Hz sync to mains. Rentang tegangan masuknya 110...300 V 60 % load dan 176...300 V full load. Daya masuk lewat 1 hard wire 3-wire (1P + N + E), sedangkan beban disambungkan ke Hard wire 3-wire (1P + N + E) for 1 zone(s). Baterainya Lead-acid external included dengan tegangan 240 V. Pengisian ulang baterainya memakan waktu sekitar 5 h. Panel kendalinya berupa Multifunction LCD status and control console. Port komunikasinya meliputi Serial port, USB port dan Available expansion slot. Bentuknya Rackmount 5U dengan dimensi 615 × 438 × 219.5 mm dan berat 78 kg. APC Indonesia memberikan garansi resmi selama 24 bulan untuk produk ini.
Garansi
- Warranty Months
- 24
- Warranty Type
- APC Indonesia Official Warranty
Jaminan
- Stock Status
- Tersedia
Spesifikasi Teknis
- Form Factor
- Rackmount 5U
- I/O Port
- • Serial port • USB port • Available expansion slot
- Output Power
- 10000 W
- Connector Type
- 1 hard wire 3-wire (1P + N + E)
- UPS Topology
- On-Line
- VA Capacity
- 10000
- Outlet Count
- Hard wire 3-wire (1P + N + E) for 1 zone(s)
- Charging Time
- 5 h
- Indicator Display
- Multifunction LCD status and control console
- Output Voltage
- Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 3 Hz sync to mains
- Waveform
- Sine wave
- Input Voltage Range
- • 110...300 V 60 % load • 176...300 V full load
- Battery
- Battery type:Lead-acid external included Battery voltage:240 V
- Dimensions
- 615 × 438 × 219.5 mm
- Weight
- 78 kg
Bandingkan dengan produk sejenis
Pilihan lain pada kategori yang sama dengan harga berdekatan.
| Sedang dilihatAPCAPC Easy UPS On-Line SRV - 10kVA Rackmount 5U, Extended Runtime |  OnesiaOnesia Online UPS Exousia XA-4100N (10 kVA, 1P/1P / 3P/1P / 3P/3P) |  APCAPC Smart-UPS On-Line SRTG - 6kVA Rack/Tower, Network Card |  APCAPC Easy UPS On-Line SRV - 10kVA Tower, Extended Runtime | |
|---|---|---|---|---|
| Harga | Rp 59.479.000 | Rp 60.090.000 | Rp 56.519.000 | Rp 54.869.000 |
| Garansi | ||||
| Warranty Months | 24 | 12 | 36 | 24 |
| Warranty Type | APC Indonesia Official Warranty | • Garansi Resmi Onesia • 1 Tahun | • APC Indonesia Official Warranty • 3 Years (UPS) • 2 Years (Battery) | APC Indonesia Official Warranty |
| Jaminan | ||||
| Stock Status | Tersedia | Tersedia | Tersedia | Tersedia |
| Spesifikasi Teknis | ||||
| Form Factor | Rackmount 5U | — | Rack/Tower | Tower |
| I/O Port | • Serial port • USB port • Available expansion slot | — | • Serial port • USB port • Pre-installed network management card 3 | • Serial port • USB port • Available expansion slot |
| Output Power | 10000 W | — | 6000 W | 10000 W |
| Connector Type | 1 hard wire 3-wire (1P + N + E) | — | 1 hard wire 3-wire (1P + N + E) | 1 hard wire 3-wire (1P + N + E) |
| UPS Topology | On-Line | Online double conversion | On-Line | On-Line |
| VA Capacity | 10000 | 10 kVA | 6000 | 10000 |
| Outlet Count | Hard wire 3-wire (1P + N + E) for 1 zone(s) | — | • 2 IEC 60320 • 1 IEC 60320 | Hard wire 3-wire (1P + N + E) for 1 zone(s) |
| Charging Time | 5 h | — | 4 h | 5 h |
| Indicator Display | Multifunction LCD status and control console | — | — | Multifunction LCD status and control console |
| Output Voltage | Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 3 Hz sync to mains | — | Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 4 Hz sync to mains | Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 3 Hz sync to mains |
| Waveform | Sine wave | — | Sine wave | Sine wave |
| Input Voltage Range | • 110...300 V 60 % load • 176...300 V full load | — | • 160...285 V full load • 100...285 V half load | • 110...300 V 60 % load • 176...300 V full load |
| Battery | Battery type:Lead-acid external included Battery voltage:240 V | — | Battery type:Lead-acid internal included Battery voltage:+/- 96 V | Battery type:Lead-acid external included Battery voltage:240 V |
| Features | — | Konfigurasi masukan dan keluaran 1P/1P / 3P/1P / 3P/3P | — | — |
| Dimensions | 615 × 438 × 219.5 mm | 310 × 810 × 890 mm | 620 × 440 × 175 mm | 485 × 380 × 368 mm |
| Weight | 78 kg | 95.0 kg | 55.9 kg | 76.5 kg |
| In The Box | — | — | • 1 x USB cable • 1 x RJ45 cable • 1 x rack mounting brackets • 1 x stabilization/wall mounting feet • 1 x installation manual • 1 x C13-C14 power cord | — |
