APC Easy UPS On-Line SRV - 3kVA Rackmount 2U
APC Easy UPS On-Line SRV adalah UPS on-line berkapasitas 3000 VA (2700 W) dengan bentuk Rackmount 2U, gelombang keluaran Sine wave serta stopkontak keluaran 6 IEC 60320 C13 dan 1 IEC 60320 C19.
Dijual oleh
Yolori Mall
APC Easy UPS On-Line SRV adalah UPS on-line berkapasitas 3000 VA dengan daya keluaran 2700 W. Bentuk gelombang keluarannya Sine wave. Tegangan keluarannya 230 V AC 1 phase dengan frekuensi 50/60 Hz +/- 3 Hz sync to mains. Rentang tegangan masuknya 110...285 V 40% load dan 180...285 V full load. Daya masuk lewat IEC 60320 C20, sedangkan beban disambungkan ke 6 IEC 60320 C13 dan 1 IEC 60320 C19. Baterainya Lead-acid internal included dengan tegangan 72 V, dengan baterai pengganti APCRBCV202. Waktu cadangan maksimumnya 3 min. Pengisian ulang baterainya memakan waktu sekitar 4 h. Panel kendalinya berupa Multifunction LCD status and control console. Port komunikasinya meliputi Serial port, USB port dan Available expansion slot. Bentuknya Rackmount 2U dengan dimensi 632 × 438 × 86 mm dan berat 28.5 kg. APC Indonesia memberikan garansi resmi selama 24 bulan untuk produk ini.
Garansi
- Warranty Months
- 24
- Warranty Type
- APC Indonesia Official Warranty
Jaminan
- Stock Status
- Tersedia
Spesifikasi Teknis
- Form Factor
- Rackmount 2U
- I/O Port
- • Serial port • USB port • Available expansion slot
- Output Power
- 2700 W
- Connector Type
- IEC 60320 C20
- UPS Topology
- On-Line
- VA Capacity
- 3000
- Backup Time
- Max runtime:3 min
- Outlet Count
- • 6 IEC 60320 C13 • 1 IEC 60320 C19
- Charging Time
- 4 h
- Indicator Display
- Multifunction LCD status and control console
- Output Voltage
- Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 3 Hz sync to mains
- Waveform
- Sine wave
- Input Voltage Range
- • 110...285 V 40% load • 180...285 V full load
- Battery
- Battery type:Lead-acid internal included Battery voltage:72 V Replacement battery:APCRBCV202
- Dimensions
- 632 × 438 × 86 mm
- Weight
- 28.5 kg
Bandingkan dengan produk sejenis
Pilihan lain pada kategori yang sama dengan harga berdekatan.
| Sedang dilihatAPCAPC Easy UPS On-Line SRV - 3kVA Rackmount 2U |  APCAPC Smart-UPS Line Interactive SMX - 1500VA Rack/tower convertible 2U |  OnesiaOnesia Online UPS Exousia XA-160N (6 kVA, 1P/1P) | OnesiaOnesia Online UPS Exousia XA-160T (6 kVA, 1P/1P) | |
|---|---|---|---|---|
| Harga | Rp 18.109.000 | Rp 19.049.000 | Rp 19.195.000 | Rp 16.920.000 |
| Garansi | ||||
| Warranty Months | 24 | 24 | 12 | 12 |
| Warranty Type | APC Indonesia Official Warranty | APC Indonesia Official Warranty | • Garansi Resmi Onesia • 1 Tahun | • Garansi Resmi Onesia • 1 Tahun |
| Jaminan | ||||
| Stock Status | Tersedia | Tersedia | Tersedia | Tersedia |
| Spesifikasi Teknis | ||||
| Form Factor | Rackmount 2U | Rack/tower convertible 2U | — | — |
| I/O Port | • Serial port • USB port • Available expansion slot | • Serial port • USB port • Available expansion slot | — | — |
| Output Power | 2700 W | 1200 W | — | — |
| Connector Type | IEC 60320 C20 | IEC 60320 C14 | — | — |
| UPS Topology | On-Line | Line interactive | Online double conversion | Online double conversion |
| VA Capacity | 3000 | 1500 | 6 kVA | 6 kVA |
| Backup Time | Max runtime:3 min | — | — | — |
| Outlet Count | • 6 IEC 60320 C13 • 1 IEC 60320 C19 | • 8 IEC 60320 C13 • 2 IEC Jumpers | — | — |
| Charging Time | 4 h | 3 h | — | — |
| Indicator Display | Multifunction LCD status and control console | Multifunction LCD status and control console | — | — |
| Output Voltage | Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 3 Hz sync to mains | Output voltage:230 V AC 1 phase Output frequency:50/60 Hz +/- 3 Hz sync to mains | — | — |
| Waveform | Sine wave | Sine wave | — | — |
| Input Voltage Range | • 110...285 V 40% load • 180...285 V full load | • 151...302 V adjustable • 160...286 V | — | — |
| Battery | Battery type:Lead-acid internal included Battery voltage:72 V Replacement battery:APCRBCV202 | Battery type:Lead-acid internal included Replacement battery:APCRBC115 | — | — |
| Features | — | — | Konfigurasi masukan dan keluaran 1P/1P | Konfigurasi masukan dan keluaran 1P/1P |
| Dimensions | 632 × 438 × 86 mm | 490 × 432 × 89 mm | — | 230 × 510 × 560 mm |
| Weight | 28.5 kg | 24.82 kg | — | 54.5 kg |
| In The Box | — | • CD with software • Documentation CD • Installation guide • Rack mounting support rails • Removable support feet • Smart UPS signalling RS-232 cable • USB cable | — | — |
