Beranda CCTVHikvision Smart IP Bullet Camera DS-2CD3651G0-IZS - 5 MP, 1/2.7" CMOS, IR 60 m

Hikvision Smart IP Bullet Camera DS-2CD3651G0-IZS - 5 MP, 1/2.7" CMOS, IR 60 m — gambar 1

1 / 3

Tentang merek· Smart IP Bullet Camera

CCTVBaruSKU: DS-2CD3651G0-IZS

Hikvision Smart IP Bullet Camera DS-2CD3651G0-IZS - 5 MP, 1/2.7" CMOS, IR 60 m

Name: Hikvision Smart IP Bullet Camera DS-2CD3651G0-IZS - 5 MP, 1/2.7" CMOS, IR 60 m
Brand: Hikvision
SKU: DS-2CD3651G0-IZS
Price: 4549000 IDR
Availability: InStock

Rp 4.549.000

Hikvision Smart IP Bullet Camera DS-2CD3651G0-IZS adalah kamera bullet IP 5 MP berlensa varifokal bermotor 2,7 sampai 13,5 mm dengan resolusi 2560 × 1920 berbentuk 4:3, sehingga bingkainya lebih tinggi. Sensornya CMOS 1/2.7 inci, inframerah pintar 60 meter, kartu memori sampai 256 GB, jalur line in dan line out, dan bodi logam IP67. Pada resolusi penuh laju bingkainya 20 per detik, dan tidak ada mikrofon bawaan.

Dijual oleh

Yolori Mall

4.4 / 7 ulasan|10 produk terjual

Chat WhatsApp Kunjungi Toko

DokumenFaktur pajak diterbitkan untuk pembelian ini

Sensor CMOS 1/2.7 inci merekam 2560 × 1920, atau sekitar lima megapiksel, dalam bingkai 4:3 sehingga bidang pandang tegaknya lebih tinggi daripada kamera 16:9: 70 derajat pada posisi lebar. Iluminasi minimumnya 0,005 lux pada F1,6 untuk gambar berwarna, dan rentang dinamis 120 dB menjaga wajah tetap terbaca saat kamera menghadap pintu kaca. Lensa varifokal bermotor 2,7 sampai 13,5 mm dengan dudukan Ø14 menggeser bidang pandang mendatar dari 97 sampai 30 derajat. DORI pada posisi lebar adalah 64 meter untuk deteksi dan 6 meter untuk identifikasi; pada posisi tele angkanya 198 dan 20 meter. Inframerah pintar menjangkau 60 meter pada 850 nm, dan braket dapat diputar pan 0° sampai 360°, dimiringkan 0° sampai 100°, serta dirotasi 0° sampai 360°. Aliran utama berjalan 20 bingkai per detik di resolusi penuh dan 25 sampai 30 bingkai pada 2560 × 1440 atau lebih rendah, dengan kompresi H.265+ dan H.264+, laju bit sampai 16 Mbps, dan satu area ROI tetap. Analitiknya lintas garis dan penyusupan. Jalur line in dan line out tersedia untuk perangkat luar, alarm masuk dan keluar menerima hingga 12 VDC pada 30 mA, dan kartu memori diterima sampai 256 GB. Daya 12 VDC dengan konsumsi maksimum 11 watt, atau PoE 802.3af kelas 3 dengan 12,9 watt. Bodi logam berdiameter 105 mm, panjang 294,5 mm, bobot 1050 gram, peringkat IP67, tahan suhu -30 °C sampai 60 °C. Kamera ini tidak punya mikrofon bawaan, peringkat IK tidak dicantumkan, dan profil ONVIF tidak dirinci datasheet. Analitiknya terbatas pada lintas garis dan penyusupan.

Garansi

Warranty Months: 12
Warranty Type: Hikvision Indonesia Official Warranty

Jaminan

Stock Status: Tersedia

Spesifikasi Teknis

Image Sensor: Image Sensor: 1/2.7" Progressive Scan CMOS Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Wide Dynamic Range (WDR): 120 dB
Resolution: Max. Resolution: 2560 × 1920 Main Stream: • 50 Hz: 20 fps (2560 × 1920), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) • 60 Hz: 20 fps (2560 × 1920), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) Sub-Stream: • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) Third Stream: • 50 Hz: 1 fps (640 × 360) • 60 Hz: 1 fps (640 × 360)
Lens: Lens Type: Varifocal Lens, motorized lens, 2.7 to 13.5 mm Focal Length & FOV: • 2.7 to 13.5 mm Horizontal FOV: 97° to 30° Vertical FOV: 70° to 22° Diagonal FOV: 128° to 37° Lens Mount: Ø14 Iris Type: Fixed Aperture: F1.6 DORI: • Varifocal lens: Wide D: 64 m O: 25 m R: 13 m I: 6 m • Varifocal lens: Tele D: 198 m O: 79 m R: 40 m I: 20 m Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
Night Vision: Supplement Light Range: Up to 60 m Smart Supplement Light: Yes IR Wavelength: 850 nm Day/Night Switch: Day, Night, Auto, Schedule
Video Compression: Video Compression: • Main stream: H.265/H.264/H.265+/H.264+ • Sub-stream: H.265/H.264/MJPEG • Third stream: H.265/H.264 Video Bit Rate: 32 Kbps to 16 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile
Audio: Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC Audio Bit Rate: 64 Kbps (G.711 ulaw/G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) Audio Sampling Rate: 8 kHz/16 kHz Environment Noise Filtering: Yes Audio: • 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium • 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Smart Detection: Basic Event: Motion detection, video tampering alarm, exception Smart Event: Line crossing detection, intrusion detection Region of Interest (ROI): 1 fixed region for main stream and sub stream Linkage: Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output
Storage: On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB
Connectivity: Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS API: Open Network Video Interface, ISAPI Simultaneous Live View: Up to 6 channels Alarm: 1 input, 1 output, (max. 12 VDC, 30 mA) Reset Key: Yes
Power: Power: • 12 VDC ± 25%, 0.9 A, max. 11 W, Ø5.5 mm coaxial power plug • PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W
Protection: Protection: IP67 (IEC 60529-2013) Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) Material: Metal
Dimensions: Dimension: Ø105 mm × 294.5 mm (4.1" × 11.6") Package Dimension: 386 mm × 156 mm × 155 mm (15.2" × 6.1" × 6.1")
Weight: Weight: Approx. 1050 g (2.3 lb.) With Package Weight: Approx. 1500 g (3.3 lb.)
