DJI Mavic 3 (Fly More Combo) - 4/3 CMOS 20MP, 46 min, 15 km

Spesifikasi Teknis

Camera

Number of Camera:2 Image Sensor: • Hasselblad Camera: 4/3 CMOS, Effective pixels: 20 MP • Tele Camera: 1/2-inch CMOS Lens • Hasselblad Camera FOV: 84° Format Equivalent: 24 mm Aperture: f/2.8 to f/11 Focus: 1 m to ∞ (with autofocus) • Tele Camera FOV: 15° Format Equivalent: 162mm Aperture: f/4.4 Focus: 3 m to ∞ Shutter Speed: • Hasselblad Camera: Electronic Shutter: 8-1/8000 s • Tele Camera: Electronic Shutter: 2-1/8000 s Digital Zoom: • Tele Camera: 7-28x

ISO Range

Hasselblad Camera • Video: 100-6400 • Still Image: 100-6400 Tele Camera • Video: 100-6400 • Still Image: 100-6400

Photo Format

Photo Format: • JPEG/DNG (RAW) Still Photography Modes • Hasselblad Camera Single shot: 20MP Photos Automatic Exposure Bracketing (AEB): 20 MP, 3/5 bracketed frames at 0.7 EV Burst shooting: 20 MP, 3/5/7 Timed: 20 MP, 2/3/5/7/10/15/20/30/60 s • Tele Camera Single shot: 12MP Photos Automatic Exposure Bracketing (AEB): 12 MP, 3/5 bracketed frames at 0.7 EV Burst shooting: 12 MP, 3/5/7 Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s

Video Format

Video Formats • Mavic 3: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265) • Mavic 3 Cine: MP4/MOV (MPEG-4 AVC/H.264, HEVC/H.265); MOV (Apple ProRes 422 HQ/422/422 LT) Max Video Bitrate • H.264/H.265 Bitrate: 200 Mbps • Apple ProRes 422 HQ Bitrate: 3,772 Mbps • Apple ProRes 422 Bitrate: 2,514 Mbps • Apple ProRes 422 LT Bitrate: 1,750 Mbps Supported File Formats: • exFAT

Resolution

Photo • Hasselblad Camera: Max Image Size 5280×3956 • Tele Camera: Max Image Size 4000×3000 Video • Hasselblad Camera, Apple ProRes 422 HQ/422/422 LT 5.1K: 5120×2700@24/25/30/48/50fps DCI 4K: 4096×2160@24/25/30/48/50/60/120fps 4K: 3840×2160@24/25/30/48/50/60/120fps • Hasselblad Camera, H.264/H.265 5.1K: 5120×2700@24/25/30/48/50fps DCI 4K: 4096×2160@24/25/30/48/50/60/120fps 4K: 3840×2160@24/25/30/48/50/60/120fps FHD: 1920×1080@24/25/30/48/50/60/120/200fps • Tele Camera, H.264/H.265 4K: 3840×2160@25/30/50fps FHD: 1920×1080@25/30/50fps

Gimbal

Stabilization: • 3-axis motorized (tilt, roll, pan) Mechanical Range • Tilt: -135° to 100° • Roll: -45° to 45° • Pan: -27° to 27° Controllable Range • Tilt: -90° to 35° • Pan: -5° to 5° Max Control Speed (tilt): • 100°/s Angular Vibration Range: • ±0.007°

Sensing

Sensing System: • Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft Forward • Measurement Range: 0.5-20 m • Detection Range: 0.5-200 m • Effective Sensing Speed: Flight Speed ≤ 15m/s • FOV: Horizontal 90°, Vertical 103° Backward • Measurement Range: 0.5-16 m • Effective Sensing Speed: Flight Speed ≤ 12m/s • FOV: Horizontal 90°, Vertical 103° Lateral • Measurement Range: 0.5-25 m • Effective Sensing Speed: Flight Speed ≤ 15m/s • FOV: Horizontal 90°, Vertical 85° Upward • Measurement Range: 0.2-10 m • Effective Sensing Speed: Flight Speed ≤ 6m/s • FOV: Front and Back 100°, Left and Right 90° Downward • Measurement Range: 0.3-18 m • Effective Sensing Speed: Flight Speed ≤ 6m/s • FOV: Front and Back 130°, Left and Right 160° Operating Environment • Forward, Backward, Left, Right, and Upward: Surface with a clear pattern and adequate lighting (lux>15) • Downward: Surface with a clear pattern and adequate lighting (lux >15). Diffuse reflective surface with diffuse reflectivity>20% (e.g. wall, tree, person)

Aircraft

Max Ascent Speed • 1 m/s (C mode) • 6 m/s (N mode) • 8 m/s (S mode) Max Descent Speed • 1 m/s (C mode) • 6 m/s (N mode) • 6 m/s (S mode) Max Flight Speed (at sea level, no wind) • 5 m/s (C mode) • 15 m/s (N mode) • 21 m/s (S mode) • No faster than 19 m/s in EU regions. Max Service Ceiling Above Sea Level: • 6000 m Max Flight Time (no wind): • 46 minutes Max Hovering Time (no wind): • 40 minutes Max Flight Distance: • 30 km Max Wind Speed Resistance: • 12 m/s Max Pitch Angle • 25° (C mode) • 30° (N mode) • 35° (S mode) Max Angular Velocity: • 200°/s Operating Temperature: • -10° to 40° C (14° to 104° F) GNSS: • GPS + Galileo + BeiDou Hovering Accuracy Range • Vertical: ±0.1 m (with Vision Positioning); ±0.5 m (with GNSS Positioning) • Horizontal: ±0.3 m (with Vision Positioning); ±0.5 m (with High-Precision Positioning System)

Transmission

Video Transmission System: • O3+ Live View Quality: • Remote Controller: 1080p@30fps/1080p@60fps Operation Frequency • 2.400-2.4835 GHz • 5.725-5.850 GHz Transmitter Power (EIRP) • 2.4 GHz: ≤33 dBm (FCC); ≤20 dBm (CE/SRRC/MIC) • 5.8 GHz: ≤33 dBm (FCC), ≤30 dBm (SRRC), ≤14 dBm (CE) Max Transmission Distance (unobstructed, free of interference and aligned with controller) • FCC: 15 km • CE: 8 km • SRRC: 8 km • MIC: 8 km Signal Transmission Ranges (FCC) • Strong Interference (urban landscape, limited line of sight, many competing signals): Approx. 1.5-3 km • Medium Interference (suburban landscape, open line of sight, some competing signals): Approx. 3-9 km • Low Interference (open landscape abundant line of sight, few competing signals): Approx. 9-15 km Max Download Bitrate • O3+ 5.5MB/s (with RC-N1 remote controller) 15MB/s (with DJI RC Pro remote controller) • Wi-Fi 6: 80MB/s Latency (depending on environmental conditions and mobile device) • 130 ms (with RC-N1 remote controller) • 120 ms (with DJI RC Pro remote controller) Antennas: • 4 antennas, 2T4R

Storage

Internal Storage • Mavic 3: 8 GB (available space is approx. 7.9 GB) • Mavic 3 Cine: 1TB (available space is approx. 934.8 GB) Supported File Formats: • exFAT

Battery

Capacity: • 5000 mAh Voltage: • 15.4 V Charging Voltage Limit: • 17.6 V Battery Type: • Li-ion 4S Energy: • 77 Wh Weight: • 335.5 g Charging Temperature: • 5° to 40° C (41° to 104° F) Charging Time: • Approx. 96 minutes

Dimensions

• Folded (without propellers): 221×96.3×90.3 mm (Length×Width×Height) • Unfolded (without propellers): 347.5×283×107.7 mm (Length×Width×Height) • Diagonal Length: 380.1 mm

Weight

• Mavic 3: 895 g • Mavic 3 Cine: 899 g
