Tentang merek· Smart IP Turret CameraCCTVBaruSKU: DS-2CD3356G2-ISU/SL
Hikvision Smart IP Turret Camera DS-2CD3356G2-ISU/SL - 5 MP, 1/2.7" CMOS, IR 40 m
Rp 4.079.000
Hikvision Smart IP Turret Camera DS-2CD3356G2-ISU/SL adalah kamera turret IP 5 MP dengan lampu strobo dan pengeras suara bawaan 1,2 watt untuk peringatan langsung di lokasi, dengan tekanan suara 95 dB pada jarak 10 cm. Kamera merekam 2592 × 1944 dengan sensor CMOS 1/2.7 inci bukaan F1,4, klasifikasi manusia dan kendaraan, mikrofon bawaan, inframerah pintar 40 meter, dan kartu memori sampai 256 GB. Peringkat IK tidak dicantumkan datasheet.
Dijual oleh
Yolori Mall
4.4 / 7 ulasan|10 produk terjual
DokumenFaktur pajak diterbitkan untuk pembelian ini
Resolusi 2592 × 1944 pada sensor CMOS 1/2.7 inci berbentuk 4:3, dengan bidang pandang 98 derajat mendatar dan 72 derajat tegak pada lensa 2,8 mm. Bukaan F1,4 dan iluminasi minimum 0,003 lux membuat gambar masih berwarna saat cahaya tinggal sedikit. Rasio sinyal terhadap derau di atas 52 dB menjaga gambar malam tidak terlalu berbintik, dan rentang dinamis 120 dB mempertahankan wajah yang membelakangi cahaya terang. Lensa tetap dengan dudukan M12, dipesan pada 2,8, 4, atau 6 mm. Pada 6 mm bidang pandangnya 51 derajat mendatar dan jangkauan deteksi DORI-nya 126 meter. Inframerah pintar menjangkau 40 meter pada 850 nm. Kepala turret dapat diputar 0° sampai 360°, dimiringkan 0° sampai 75°, dan dirotasi 0° sampai 360°. Alarm gerak dapat dibatasi pada manusia dan kendaraan. Perlindungan perimeter mencakup lintas garis, penyusupan, serta masuk dan keluar area, ditambah deteksi barang tertinggal, barang hilang, perubahan pemandangan, dan pengecualian audio. Pemicu tautannya mencakup lampu strobo dan peringatan suara, dan kamera membawa pengeras suara 1,2 watt dengan tekanan suara 95 dB pada jarak 10 cm. Mikrofon bawaan serta jalur line in dan line out melengkapi audio, sedangkan alarm masuk dan keluar menerima hingga 24 VDC atau 24 VAC pada 500 mA. Kartu memori sampai 256 GB, dan ONVIF mencakup Profile S, G, dan T. Daya 12 VDC dengan konsumsi maksimum 7,8 watt, atau PoE 802.3af kelas 3 dengan 8,8 watt. Bodi berdiameter 138,3 mm, tinggi 124,5 mm, bobot 820 gram, peringkat IP67, tahan suhu -30 °C sampai 60 °C. Peringkat IK tidak dicantumkan, jadi ketahanan terhadap benturan tidak dijamin principal. Kartu memori dibatasi 256 GB, dan port jaringannya 10/100 Mbps.
Garansi
- Warranty Months
- 12
- Warranty Type
- Hikvision Indonesia Official Warranty
Jaminan
- Stock Status
- Tersedia
Spesifikasi Teknis
- Image Sensor
- Image Sensor: 1/2.7" Progressive Scan CMOS Min. Illumination: Color: 0.003 Lux @ (F1.4, AGC ON), B/W: 0 Lux with IR Wide Dynamic Range (WDR): 120 dB SNR: ≥ 52 dB
- Resolution
- Max. Resolution: 2592 × 1944 Main Stream: • 50 Hz: 25 fps (2592 × 1944, 2688 × 1520, 1920 × 1080, 1280 × 720) • 60 Hz: 24 fps (2592 × 1944) 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) Sub-Stream: • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) Third Stream: • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) Fourth Stream: • 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
- Lens
- Lens Type: Fixed focal lens, 2.8, 4, and 6 mm optional Focal Length & FOV: • 2.8 mm Horizontal FOV: 98° Vertical FOV: 72° Diagonal FOV: 131° • 4 mm Horizontal FOV: 80° Vertical FOV: 58° Diagonal FOV: 104° • 6 mm Horizontal FOV: 51° Vertical FOV: 37° Diagonal FOV: 66° Lens Mount: M12 Iris Type: Fixed Aperture: F1.4 DORI: • 2.8 mm D: 64 m O: 25 m R: 12 m I: 6 m • 4 mm D: 77 m O: 30 m R: 15 m I: 7 m • 6 mm D: 126 m O: 50 m R: 25 m I: 12 m Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
- Night Vision
- Supplement Light Type: IR Supplement Light Range: Up to 40 m Smart Supplement Light: Yes IR Wavelength: 850 nm Day & Night: IR cut filter Day/Night Switch: Day, Night, Auto, Schedule
- Video Compression
- Video Compression: • Main stream: H.265/H.264/H.264+/H.265+ • Sub-stream: H.265/H.264/MJPEG • Third stream: H.265/H.264 • Fourth stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 16 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile Bit Rate Control: CBR/VBR Scalable Video Coding (SVC): H.264 and H.265 encoding
- Audio
- Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Environment Noise Filtering: Yes Built-in Microphone: Yes Built-in Speaker: Power: 1.2 W. Max. sound pressure level: 10 cm: 95 dB Audio: • 1 input (line in), two-core terminal block, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium • 1 output (line out), two-core terminal block, max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium
- Smart Detection
- Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exception Smart Event: Unattended baggage detection, object removal detection, scene change detection, audio exception detection Perimeter Protection: Line crossing detection, intrusion detection, region entrance detection, region exiting detection Face Capture: Yes Region of Interest (ROI): 5 fixed regions for main stream and sub-stream Target Cropping: Yes Linkage: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning
- Storage
- On-Board Storage: Built-in micro SD/SDHC/SDXC slot, up to 256 GB Network Storage: • MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) • Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
- Connectivity
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, ARP, SNMP API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP Simultaneous Live View: Up to 6 channels Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Alarm: • Visual alarm • 1 input, 1 output (max. 24 VDC/24 VAC, 500 mA) Reset Key: Yes
- Power
- Power: • 12 VDC ± 25%, 0.65 A, max. 7.8 W, Ø5.5 mm coaxial power plug, reverse polarity protection • PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.15 A, max. 8.8 W
- Protection
- Protection: IP67 (IEC 60529-2013) Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
- Dimensions
- Dimension: Ø138.3 mm × 124.5 mm (Ø5.4" × 4.9") Package Dimension: 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9")
- Weight
- Weight: Approx. 820 g (1.8 lb.) With Package Weight: Approx. 1120 g (2.5 lb.)
