Beranda CCTVHikvision Smart IP Turret Camera DS-2CD3323G2-IU - 2 MP, 1/2.7" CMOS, IR 40 m

Hikvision Smart IP Turret Camera DS-2CD3323G2-IU - 2 MP, 1/2.7" CMOS, IR 40 m — gambar 1

1 / 3

Tentang merek· Smart IP Turret Camera

CCTVBaruSKU: DS-2CD3323G2-IU

Hikvision Smart IP Turret Camera DS-2CD3323G2-IU - 2 MP, 1/2.7" CMOS, IR 40 m

Name: Hikvision Smart IP Turret Camera DS-2CD3323G2-IU - 2 MP, 1/2.7" CMOS, IR 40 m
Brand: Hikvision
SKU: DS-2CD3323G2-IU
Price: 2899000 IDR
Availability: InStock

Rp 2.899.000

Hikvision Smart IP Turret Camera DS-2CD3323G2-IU adalah kamera turret IP 2 MP yang alarm geraknya dapat dibatasi pada manusia dan kendaraan, dengan mikrofon bawaan yang merekam suara bersama gambar. Sensornya CMOS 1/2.7 inci bukaan F1,6, inframerah pintarnya 40 meter, dan tersedia jalur line in serta line out. Kartu memori diterima sampai 512 GB, bodinya paduan aluminium dengan peringkat IP67.

Dijual oleh

Yolori Mall

4.4 / 7 ulasan|10 produk terjual

Chat WhatsApp Kunjungi Toko

DokumenFaktur pajak diterbitkan untuk pembelian ini

Sensor CMOS 1/2.7 inci merekam 1920 × 1080, atau 2 megapiksel, dengan bukaan F1,6 dan iluminasi minimum 0,005 lux untuk gambar berwarna. Pada lensa 2,8 mm bidang pandangnya 112 derajat mendatar dan 61 derajat tegak. Rentang dinamis 120 dB menjaga wajah tetap terbaca saat kamera menghadap pintu kaca, dan rasio sinyal terhadap derau di atas 52 dB menekan bintik pada gambar malam. Lensa tetap dengan dudukan M12, dipesan pada 2,8, 4, atau 6 mm. Kedalaman medannya mulai 1 meter pada 2,8 mm dan 2,8 meter pada 6 mm. Lensa 6 mm menyempitkan bidang pandang ke 56 derajat mendatar dan memperpanjang DORI hingga 85 meter untuk deteksi serta 8 meter untuk identifikasi. Inframerah pintar menjangkau 40 meter pada 850 nm, dan kepala turret dapat diputar 0° sampai 360°, dimiringkan 0° sampai 75°, serta dirotasi 0° sampai 360°. Alarm gerak dapat dibatasi pada manusia dan kendaraan. Perlindungan perimeter mencakup lintas garis, penyusupan, serta masuk dan keluar area, dan analitik lain meliputi berkeliaran, kerumunan, orang berlari, parkir, barang tertinggal, barang hilang, serta diagnosis mutu video. Aliran utama berjalan 25 atau 30 bingkai per detik dengan laju bit 32 Kbps sampai 8 Mbps. Mikrofon bawaan merekam suara, jalur line in dan line out tersedia untuk perangkat luar, dan kartu memori diterima sampai 512 GB. Daya 12 VDC dengan konsumsi maksimum 7 watt, atau PoE 802.3af kelas 3 dengan 9 watt. Bodi paduan aluminium berdiameter 127,3 mm, tinggi 96,3 mm, bobot 635 gram, peringkat IP67, tahan suhu -30 °C sampai 60 °C. Datasheet tidak mencantumkan peringkat IK, jadi ketahanan terhadap benturan tidak dijamin principal. ONVIF-nya mencakup Profile S dan G, tanpa Profile T. Tidak ada pengeras suara bawaan, dan port jaringannya 10/100 Mbps.

Garansi

Warranty Months: 12
Warranty Type: Hikvision Indonesia Official Warranty

Jaminan

Stock Status: Tersedia

Spesifikasi Teknis

Image Sensor: Image Sensor: 1/2.7" Progressive Scan CMOS Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Wide Dynamic Range (WDR): 120 dB SNR: ≥ 52 dB
Resolution: Max. Resolution: 1920 × 1080 Main Stream: • 50 Hz: 25 fps (1920 × 1080, 1280 × 720) • 60 Hz: 30 fps (1920 × 1080, 1280 × 720) Sub-Stream: • 50 Hz: 25 fps (640 × 480, 640 × 360) • 60 Hz: 30 fps (640 × 480, 640 × 360) Third Stream: • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) Fourth Stream: • 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)
Lens: Lens Type: Fixed focal lens, 2.8, 4, and 6 mm optional Focal Length & FOV: • 2.8 mm Horizontal FOV: 112° Vertical FOV: 61° Diagonal FOV: 132.4° • 4 mm Horizontal FOV: 91° Vertical FOV: 47.8° Diagonal FOV: 110.2° • 6 mm Horizontal FOV: 56° Vertical FOV: 29.8° Diagonal FOV: 65.3° Lens Mount: M12 Iris Type: Fixed Aperture: F1.6 Depth of Field: • 2.8 mm 1 m to ∞ • 4 mm 1.1 m to ∞ • 6 mm 2.8 m to ∞ DORI: • 2.8 mm D: 42 m O: 16 m R: 8 m I: 4 m • 4 mm D: 52 m O: 20 m R: 10 m I: 5 m • 6 mm D: 85 m O: 33 m R: 17 m I: 8 m Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
Night Vision: Supplement Light Type: IR Supplement Light Range: Up to 40 m Smart Supplement Light: Yes IR Wavelength: 850 nm Day & Night: IR cut filter Day/Night Switch: Day, Night, Auto, Schedule
Video Compression: Video Compression: • Main stream: H.265/H.264/H.264+/H.265+ • Sub-stream: H.265/H.264/MJPEG • Third stream: H.265/H.264 • Fourth stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile Scalable Video Coding (SVC): H.264 and H.265 encoding Bit Rate Control: CBR, VBR
Audio: Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/48 kHz Environment Noise Filtering: Yes Built-in Microphone: Yes, 1 built-in microphone Audio: • 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium • 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Smart Detection: Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception Smart Event: Unattended baggage detection, object removal detection, loitering detection, people gathering detection, people running detection, parking detection, video quality diagnosis Perimeter Protection: • Line crossing, intrusion, region entrance, region exiting • Support alarm triggering by specified target types (human and vehicle) Face Capture: Yes Region of Interest (ROI): 5 fixed regions for main stream and sub-stream Target Cropping: Yes Privacy Mask: 8 programmable polygon privacy masks Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture
Storage: On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Network Storage: • NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) • Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Connectivity: Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets API: ONVIF (Profile S, Profile G), ISAPI, SDK, ISUP Simultaneous Live View: Up to 6 channels Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Alarm: 1 input, 1 output (max. 12 VDC, 30 mA) Reset Key: Yes
Power: Power: • 12 VDC ± 25%, 0.58 A, max. 7.0 W, Ø5.5 mm coaxial power plug, reverse polarity protection • PoE: IEEE 802.3af, Class 3, max. 9 W
Protection: Protection: IP67: IEC 60529-2013 Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Material: Aluminum alloy body
Dimensions: Dimension: Ø127.3 mm × 96.3 mm (Ø5.0" × 3.8") Package Dimension: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
Weight: Weight: Approx. 635 g (1.4 lb.) With Package Weight: Approx. 861 g (1.9 lb.)

Bandingkan dengan produk sejenis

Pilihan lain pada kategori yang sama dengan harga berdekatan.

Tampilkan hanya yang berbeda

	Sedang dilihatHikvisionHikvision Smart IP Turret Camera DS-2CD3323G2-IU - 2 MP, 1/2.7" CMOS, IR 40 m	HikvisionHikvision Smart IP Bullet Camera DS-2CD3023G2-IU - 2 MP, 1/2.7" CMOS, IR 40 m	HikvisionHikvision Smart IP Bullet Camera DS-2CD3T51G0-IUF - 5 MP, 1/2.7" CMOS, IR 60 m	HikvisionHikvision Smart IP Bullet Camera DS-2CD3023G0-I - 2 MP, 1/2.8" CMOS, IR 40 m
Harga	Rp 2.899.000	Rp 2.899.000	Rp 2.939.000	Rp 2.959.000
Garansi
Warranty Months	12	12	12	12
Warranty Type	Hikvision Indonesia Official Warranty	Hikvision Indonesia Official Warranty	Hikvision Indonesia Official Warranty	Hikvision Indonesia Official Warranty
Jaminan
Stock Status	Tersedia	Tersedia	Tersedia	Tersedia
Spesifikasi Teknis
Camera Type	—	Type: AcuSense Fixed Bullet Network Camera Signal: IP	—	Type: IR Fixed Network Bullet Camera Signal: IP
Image Sensor	Image Sensor: 1/2.7" Progressive Scan CMOS Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Wide Dynamic Range (WDR): 120 dB SNR: ≥ 52 dB	Image Sensor: 1/2.7" Progressive Scan CMOS	Image Sensor: 1/2.7" Progressive Scan CMOS Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR Wide Dynamic Range (WDR): 120 dB	Image Sensor: 1/2.8" Progressive Scan CMOS Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR Wide Dynamic Range: 120dB
Resolution	Max. Resolution: 1920 × 1080 Main Stream: • 50 Hz: 25 fps (1920 × 1080, 1280 × 720) • 60 Hz: 30 fps (1920 × 1080, 1280 × 720) Sub-Stream: • 50 Hz: 25 fps (640 × 480, 640 × 360) • 60 Hz: 30 fps (640 × 480, 640 × 360) Third Stream: • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) Fourth Stream: • 50 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 10 fps (1280 × 720, 640 × 480, 640 × 360)	Max. Resolution: 1920 × 1080	Max. Resolution: 2560 × 1920 Main Stream: • 50 Hz: 20 fps (2560 × 1920), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) • 60 Hz: 20 fps (2560 × 1920), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) Sub-Stream: • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) Third Stream: • 50 Hz: 1 fps (640 × 360) • 60 Hz: 1 fps (640 × 360)	Max. Resolution: 1920 × 1080 Main Stream: • 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) • 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub-Stream: • 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) • 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Third Stream: • 50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288) • 60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
Lens	Lens Type: Fixed focal lens, 2.8, 4, and 6 mm optional Focal Length & FOV: • 2.8 mm Horizontal FOV: 112° Vertical FOV: 61° Diagonal FOV: 132.4° • 4 mm Horizontal FOV: 91° Vertical FOV: 47.8° Diagonal FOV: 110.2° • 6 mm Horizontal FOV: 56° Vertical FOV: 29.8° Diagonal FOV: 65.3° Lens Mount: M12 Iris Type: Fixed Aperture: F1.6 Depth of Field: • 2.8 mm 1 m to ∞ • 4 mm 1.1 m to ∞ • 6 mm 2.8 m to ∞ DORI: • 2.8 mm D: 42 m O: 16 m R: 8 m I: 4 m • 4 mm D: 52 m O: 20 m R: 10 m I: 5 m • 6 mm D: 85 m O: 33 m R: 17 m I: 8 m Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°	Focal Length & FOV: • 2.8 mm Horizontal FOV: 112° Vertical FOV: 61° Diagonal FOV: 132.4° • 4 mm Horizontal FOV: 91° Vertical FOV: 47.8° Diagonal FOV: 110.2° • 6 mm Horizontal FOV: 56° Vertical FOV: 29.8° Diagonal FOV: 65.3° Aperture: F1.6	Focal Length & FOV: • 2.8 mm Horizontal FOV: 99° Vertical FOV: 72° Diagonal FOV: 130° • 4 mm Horizontal FOV: 78° Vertical FOV: 57° Diagonal FOV: 100° • 6 mm Horizontal FOV: 49° Vertical FOV: 36° Diagonal FOV: 63° Lens Mount: M12 Aperture: F1.6 DORI: • 2.8 mm D: 63 m O: 25 m R: 12 m I: 6 m • 4 mm D: 79 m O: 31 m R: 15 m I: 7 m • 6 mm D: 128 m O: 50 m R: 25 m I: 12 m Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°	Lens Type: 2.8/4/6/8 mm Focus: Fixed Aperture: F2.0 FOV: • 2.8 mm Horizontal FOV: 103° Vertical FOV: 59° Diagonal FOV: 118° • 4 mm Horizontal FOV: 86° Vertical FOV: 46° Diagonal FOV: 102° • 6 mm Horizontal FOV: 54° Vertical FOV: 30° Diagonal FOV: 62° • 8 mm Horizontal FOV: 43° Vertical FOV: 23° Diagonal FOV: 50° Lens Mount: M12 Auto-Iris: No
Night Vision	Supplement Light Type: IR Supplement Light Range: Up to 40 m Smart Supplement Light: Yes IR Wavelength: 850 nm Day & Night: IR cut filter Day/Night Switch: Day, Night, Auto, Schedule	Supplement Light Type: IR Supplement Light Range: Up to 40 m Smart Supplement Light: Yes	Supplement Light Range: Up to 60 m Smart Supplement Light: Yes IR Wavelength: 850 nm Day/Night Switch: Day, Night, Auto, Schedule	IR Range: Up to 40 m Wavelength: 850 nm Day/Night Switch: Day/Night/Auto/Schedule
Video Compression	Video Compression: • Main stream: H.265/H.264/H.264+/H.265+ • Sub-stream: H.265/H.264/MJPEG • Third stream: H.265/H.264 • Fourth stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile Scalable Video Coding (SVC): H.264 and H.265 encoding Bit Rate Control: CBR, VBR	Video Compression: • Main stream: H.265/H.264/H.264+/H.265+ • Sub-stream: H.265/H.264/MJPEG • Third stream: H.265/H.264 • Fourth stream: H.265/H.264/MJPEG Video Bit Rate: 32 Kbps to 8 Mbps	Video Compression: • Main stream: H.265/H.264/H.265+/H.264+ • Sub-stream: H.265/H.264/MJPEG • Third stream: H.265/H.264 Video Bit Rate: 32 Kbps to 16 Mbps H.264 Type: Baseline Profile/Main Profile/High Profile H.265 Type: Main Profile	Video Compression: • Main stream: H.265/H.264 • Sub-stream/third stream: H.265/H.264/MJPEG Video Bit Rate: 256 Kbps to 16 Mbps H.264 Type: Main Profile/High Profile H.265 Type: Main Profile H.264+: Main stream supports H.265+: Main stream supports
Audio	Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/48 kHz Environment Noise Filtering: Yes Built-in Microphone: Yes, 1 built-in microphone Audio: • 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium • 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium	Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Built-in Microphone: Yes, 1 built-in microphone	Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC Audio Bit Rate: 64 Kbps(G.711 ulaw/G.711 alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 160 Kbps(MP2L2)/16 to 64 Kbps(AAC) Audio Sampling Rate: 8 kHz/16 kHz Environment Noise Filtering: Yes Built-in Microphone: Yes	—
Smart Detection	Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception Smart Event: Unattended baggage detection, object removal detection, loitering detection, people gathering detection, people running detection, parking detection, video quality diagnosis Perimeter Protection: • Line crossing, intrusion, region entrance, region exiting • Support alarm triggering by specified target types (human and vehicle) Face Capture: Yes Region of Interest (ROI): 5 fixed regions for main stream and sub-stream Target Cropping: Yes Privacy Mask: 8 programmable polygon privacy masks Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture	Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)) Smart Event: Unattended baggage detection, object removal detection, loitering detection, people gathering detection, people running detection, parking detection, video quality diagnosis Perimeter Protection: Line crossing, intrusion, region entrance, region exiting; support alarm triggering by specified target types (human and vehicle)	Basic Event: Motion detection, video tampering alarm, exception Smart Event: Line crossing detection, intrusion detection Region of Interest (ROI): 1 fixed region for main stream and sub-stream Linkage: Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture	Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) Smart Event: • Line crossing detection, 1 line configurable • Intrusion detection, up to 1 region configurable • Unattended baggage detection, 1 region configurable • Object removal detection, 1 region configurable • Face detection: detects faces • Scene change detection Face Detection: Yes Region of Interest (ROI): 5 fixed region for main stream and sub-stream
Storage	On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Network Storage: • NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) • Together with high-end Hikvision memory card, memory card encryption and health detection are supported.	On-Board Storage: microSD/microSDHC/microSDXC, up to 512 GB	On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB	On-board Storage: Built-in Micro SD/SDHC/SDXC slot, up to 128 GB Network Storage: Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS, SMB/CIFS), ANR
Connectivity	Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets API: ONVIF (Profile S, Profile G), ISAPI, SDK, ISUP Simultaneous Live View: Up to 6 channels Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface Alarm: 1 input, 1 output (max. 12 VDC, 30 mA) Reset Key: Yes	Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, SNMP, WebSocket, WebSockets API: ONVIF (Profile S, Profile G), ISAPI, SDK, ISUP	Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS API: Open Network Video Interface, ISAPI Simultaneous Live View: Up to 6 channels Reset Key: Yes	Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port Video Output: No Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS API: ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, Ehome
Power	Power: • 12 VDC ± 25%, 0.58 A, max. 7.0 W, Ø5.5 mm coaxial power plug, reverse polarity protection • PoE: IEEE 802.3af, Class 3, max. 9 W	Power: • 12 VDC ± 25%, reverse polarity protection, 0.5 A, max. 6 W, Ø 5.5 mm coaxial power plug • PoE: IEEE 802.3af, Class 3, max. 7.5 W	Power: • 12 VDC ± 25%, 0.55 A, max. 6.5 W, Ø5.5 mm coaxial power plug • PoE: 802.3af, Class 3, 36 V to 57 V, 0.24 A to 0.14 A, max. 8.5 W	Power Supply: 12 VDC ± 25%, Ø 5.5 mm coaxial power plug; PoE (802.3af, class 3) Power Consumption and Current: • 12 VDC, 0.5 A, max. 6 W • PoE (802.3af, 37 V to 57 V), 0.2 A to 0.1 A, max. 7.5 W
Protection	Protection: IP67: IEC 60529-2013 Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Material: Aluminum alloy body	Protection: IP67: IEC 60529-2013, IK10: IEC 62262:2002 Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)	Protection: IP67 (IEC 60529-2013) Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) Material: Metal & Plastic	Protection: IP67 Startup and Operating Conditions: -30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
Dimensions	Dimension: Ø127.3 mm × 96.3 mm (Ø5.0" × 3.8") Package Dimension: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")	Dimension: Ø 74.4 mm × 179.2 mm (Ø 2.9" × 7.1")	Dimension: 83.7 mm × 80.7 mm × 205.6 mm (3.3" × 3.2" × 8.1") Package Dimension: 260 mm × 125 mm × 125 mm (10.2" × 4.9" × 4.9")	Camera Dimension: • Camera: Ø 70 mm × 155.03 mm (Ø 2.8" × 6.1") • Package: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.7")
Weight	Weight: Approx. 635 g (1.4 lb.) With Package Weight: Approx. 861 g (1.9 lb.)	Weight: Approx. 510 g (1.1 lb.) Material: Metal	Weight: Approx. 430 g (0.95 lb.) With Package Weight: Approx. 648 g (1.42 lb.)	Camera Weight: • Camera: Approx. 420 g (0.9 lb.) • With Package: Approx. 700 g (1.5 lb.)
