Tentang merek· Switch UnmanagedHikvision Switch Unmanaged DS-3E0516-E(B) - 16 Port Gigabit
Hikvision Switch Unmanaged DS-3E0516-E(B) adalah Switch dengan Ports: 16 × Gigabit RJ45 port.
Dijual oleh
Yolori Mall
Hikvision Switch Unmanaged DS-3E0516-E(B) adalah Switch dengan Ports: 16 × Gigabit RJ45 port. Dari sisi kinerja, tercatat Switching Capacity: 32 Gbps; Packet Forwarding Rate: 23.81 Mpps. Switch dari Hikvision ini juga dibekali Model: DS-3E0516-E(B); Shell: Metal material, fan-free design; Gross Weight: 2.07 kg (4.56 lb); Installation Mode: Metal material, fan-free design; MAC Address Table: 8 K; Internal Cache: 4.10 Mbits. Switch dari Hikvision ini juga dibekali Power Supply: 220 V AC, 50/60 Hz, Max. 0.3 A. Dimensinya 257.0 mm × 44.5 mm × 175.8 mm (10.1'' × 1.8'' × 6.9''). Beratnya 1.20 kg (2.60 lb). Untuk lingkungan operasi, tercatat Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage Temperature: –40˚C to 85˚C (–40˚F to 185˚F); Operating Humidity: 5% to 95% (no condensation); Relative Humidity: 5% to 95% (no condensation). Sertifikasi dan kepatuhan standarnya meliputi EMC mencakup FCC (47 CFR Part 15, Subpart B), CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020), IC (ICES-003: Issue 7:2020) dan RCM (AS/NZS CISPR 32: 2015); Safety mencakup UL (UL 60950-1), CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition) dan CE-LVD (EN 62368-1: 2014+A11: 2017). Hikvision memberikan Hikvision Indonesia Official Warranty selama 12 bulan untuk produk ini.
Garansi
- Warranty Months
- 12
- Warranty Type
- Hikvision Indonesia Official Warranty
Jaminan
- Stock Status
- Tersedia
Spesifikasi Teknis
- Port Count
- Ports: 16 × Gigabit RJ45 port
- Bandwidth
- • Switching Capacity: 32 Gbps • Packet Forwarding Rate: 23.81 Mpps
- Environment
- • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: –40˚C to 85˚C (–40˚F to 185˚F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation)
- Certification
- EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368-1: 2014+A11: 2017)
- Features
- • Model: DS-3E0516-E(B) • Shell: Metal material, fan-free design • Gross Weight: 2.07 kg (4.56 lb) • Installation Mode: Metal material, fan-free design • MAC Address Table: 8 K • Internal Cache: 4.10 Mbits
- Dimensions
- 257.0 mm × 44.5 mm × 175.8 mm (10.1'' × 1.8'' × 6.9'')
- Weight
- 1.20 kg (2.60 lb)
- Power
- Power Supply: 220 V AC, 50/60 Hz, Max. 0.3 A
Bandingkan dengan produk sejenis
Pilihan lain pada kategori yang sama dengan harga berdekatan.
| Sedang dilihatHikvisionHikvision Switch Unmanaged DS-3E0516-E(B) - 16 Port Gigabit |  HikvisionHikvision Switch Unmanaged PoE DS-3T0306HP-E/HS - 4 Port Fast Ethernet |  HikvisionHikvision Switch Unmanaged PoE DS-3E0505P-E - 4 Port Gigabit |  HikvisionHikvision Switch Unmanaged PoE DS-3E0510P-E/M - 8 Port Gigabit | |
|---|---|---|---|---|
| Harga | Rp 1.699.000 | Rp 1.799.000 | Rp 1.389.000 | Rp 2.009.000 |
| Garansi | ||||
| Warranty Months | 12 | 12 | 12 | 12 |
| Warranty Type | Hikvision Indonesia Official Warranty | Hikvision Indonesia Official Warranty | Hikvision Indonesia Official Warranty | Hikvision Indonesia Official Warranty |
| Jaminan | ||||
| Stock Status | Tersedia | Tersedia | Tersedia | Tersedia |
| Spesifikasi Teknis | ||||
| Port Count | Ports: 16 × Gigabit RJ45 port | — | Ports: 4 × Gigabit PoE port,1 × Gigabit RJ45 port | Ports: 8 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port |
| PoE | — | — | • PoE Standard: IEEE 802.3af,IEEE 802.3at • PoE Power Pin: End-span: 1/2(+), 3/6(-) • PoE Port: PoE: Ports 1 to 4 • Max. Port Power: 30 W • PoE Power Budget: 60 W | • PoE Standard: IEEE 802.3af;IEEE 802.3at • PoE Power Pin: End-span: 1/2(+), 3/6(-) • PoE Port: PoE: Ports 1 to 8 • Max. Port Power: 30 W • PoE Power Budget: 58 W |
| Bandwidth | • Switching Capacity: 32 Gbps • Packet Forwarding Rate: 23.81 Mpps | — | • Switching Capacity: 10 Gbps • Packet Forwarding Rate: 7.44 Mpps | • Switching Capacity: 20 Gbps • Packet Forwarding Rate: 14.88 Mpps |
| Environment | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: –40˚C to 85˚C (–40˚F to 185˚F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation) | — | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation) | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: –40 °C to 85 °C (–40 °F to 185 °F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation) |
| Certification | EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368-1: 2014+A11: 2017) | — | EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368-1: 2014+A11: 2017) | EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368-1: 2014+A11: 2017) Chemistry: • CE-RoHS (201165EU); • WEEE (201219EU); • Reach (Regulation (EC) No.19072006) |
| Features | • Model: DS-3E0516-E(B) • Shell: Metal material, fan-free design • Gross Weight: 2.07 kg (4.56 lb) • Installation Mode: Metal material, fan-free design • MAC Address Table: 8 K • Internal Cache: 4.10 Mbits | — | • Model: DS-3E0505P-E • Shell: Metal material, fan-free design • Gross Weight: 0.84 kg (1.85 lb) • Installation Mode: Desk-Mounted,Wall-Mounted; • Surge Protection: 6 kV • MAC Address Table: 2 K • Internal Cache: 1 Mbits | • Model: DS-3E0510P-E/M • Shell: Metal material • Gross Weight: 1.366 kg (3.01 lb) • Installation Mode: Desk-Mounted,Wall-Mounted • Surge Protection: 6 kV • MAC Address Table: 4 K • Internal Cache: 1.5 Mbits |
| Dimensions | 257.0 mm × 44.5 mm × 175.8 mm (10.1'' × 1.8'' × 6.9'') | — | 105.0 mm × 27.6 mm × 83.1 mm (4.1'' × 1.1'' × 3.3'') | 217.6 mm × 27.8 mm × 108.55 mm (8.6'' × 1.1'' × 4.3'') |
| Weight | 1.20 kg (2.60 lb) | — | 0.26 kg (0.57 lb) | 0.635 kg (1.40 lb) |
| Power | Power Supply: 220 V AC, 50/60 Hz, Max. 0.3 A | — | • Power Supply: 48 V DC, 1.35 A • Max. Power Consumption: 65 W • Power Consumption in Idle: 5 W | • Power Supply: 48 V DC, 1.35 A • Max. Power Consumption: 65 W • Power Consumption in Idle: 7 W |
