Hikvision Switch Unmanaged DS-3E0524-E(B) - 24 Port Gigabit

Name: Hikvision Switch Unmanaged DS-3E0524-E(B) - 24 Port Gigabit
Brand: Hikvision
SKU: DS-3E0524-E(B)
Price: 2309000 IDR
Availability: InStock

Rp 2.309.000

Hikvision Switch Unmanaged DS-3E0524-E(B) adalah Switch dengan Ports: 24 × Gigabit RJ45 port.

Dijual oleh

Yolori Mall

4.4 / 7 ulasan|10 produk terjual

Chat WhatsApp Kunjungi Toko

DokumenFaktur pajak diterbitkan untuk pembelian ini

Hikvision Switch Unmanaged DS-3E0524-E(B) adalah Switch dengan Ports: 24 × Gigabit RJ45 port. Dari sisi kinerja, tercatat Switching Capacity: 48 Gbps; Packet Forwarding Rate: 35.72 Mpps. Switch dari Hikvision ini juga dibekali Model: DS-3E0524-E(B); Shell: Metal material, fan-free design; Gross Weight: 2.47 kg (5.44 lb); Installation Mode: Metal material, fan-free design; Surge Protection: 6 kV; MAC Address Table: 8 K; Internal Cache: 4.10 Mbits. Switch dari Hikvision ini juga dibekali Power Supply: 220 V AC, 50/60 Hz, Max. 0.7 A. Dimensinya 335.0 mm × 44.5 mm × 175.8 mm (13.2'' × 1.8'' × 6.9''). Beratnya 1.60 kg (3.50 lb). Untuk lingkungan operasi, tercatat Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F); Storage Temperature: –40˚C to 85˚C (–40˚F to 185˚F); Operating Humidity: 5% to 95% (no condensation); Relative Humidity: 5% to 95% (no condensation). Sertifikasi dan kepatuhan standarnya meliputi EMC mencakup FCC (47 CFR Part 15, Subpart B), CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020), IC (ICES-003: Issue 7:2020) dan RCM (AS/NZS CISPR 32: 2015); Safety mencakup UL (UL 60950-1), CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition) dan CE-LVD (EN 62368-1: 2014+A11: 2017). Hikvision memberikan Hikvision Indonesia Official Warranty selama 12 bulan untuk produk ini.

Bandingkan dengan produk sejenis

Pilihan lain pada kategori yang sama dengan harga berdekatan.

Tampilkan hanya yang berbeda

	Sedang dilihatHikvisionHikvision Switch Unmanaged DS-3E0524-E(B) - 24 Port Gigabit	HikvisionHikvision Switch Unmanaged PoE DS-3T0506HP-E/HS - 4 Port Gigabit	HikvisionHikvision Switch Smart DS-3E1516-EI - 16 Port Gigabit	HikvisionHikvision Switch Unmanaged PoE DS-3E0510P-E/M - 8 Port Gigabit
Harga	Rp 2.309.000	Rp 2.309.000	Rp 2.159.000	Rp 2.009.000
Garansi
Warranty Months	12	12	12	12
Warranty Type	Hikvision Indonesia Official Warranty	Hikvision Indonesia Official Warranty	Hikvision Indonesia Official Warranty	Hikvision Indonesia Official Warranty
Jaminan
Stock Status	Tersedia	Tersedia	Tersedia	Tersedia
Spesifikasi Teknis
Security	—	Port Isolation: Ports 1 to 4: port isolation mode to improve network security.	Port Isolation: • Ports 1 to 16: port isolation mode to improve network security • Ports in an isolation group cannot communicate with each other, but they can communicate with ports outside the isolation group.	—
Port Count	Ports: 24 × Gigabit RJ45 port	Ports: 4 × Gigabit PoE port,2 × Gigabit fiber optical port	Ports: 16 × Gigabit RJ45 port	Ports: 8 × Gigabit PoE port,1 × Gigabit RJ45 port,1 × Gigabit fiber optical port
Management	—	—	System Maintenance: • Support device management via web. • Support DHCP Client. Enabled by default for dynamic assignment of management IP addresses. • Support Super IP, which is a configurable IP address (default: 10.180.190.200) for direct access. • Support management via Hik-Central Pro. • Support remote management via Hik-Partner Pro. • Support cable detection. Abnormal open circuits and short circuits as well as network cable length can be detected. • Support 802.1ab LLDP for peer device discovery. • Support port mirroring for fault locating. HPP: • Support one-click activation and remote management via Hik-Partner Pro. Functions supported: • 1. Display the port rate. • 2. Display the port bandwidth utilization rate. • 3. Display topology information. • 4. Display the alarm status. • 5. Restart ports and devices. • 6. Remotely upgrade the device.	—
PoE	—	• PoE Standard: IEEE 802.3af,IEEE 802.3at,IEEE 802.3bt • PoE Power Pin: 8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-) PoE Port: • Hi-PoE: Port 1 • PoE: Ports 2 to 4 Max. Port Power: • Port 1: 60 W • Ports 2 to 4: 30 W • PoE Power Budget: 65 W	—	• PoE Standard: IEEE 802.3af;IEEE 802.3at • PoE Power Pin: End-span: 1/2(+), 3/6(-) • PoE Port: PoE: Ports 1 to 8 • Max. Port Power: 30 W • PoE Power Budget: 58 W
Bandwidth	• Switching Capacity: 48 Gbps • Packet Forwarding Rate: 35.72 Mpps	• Switching Capacity: 12 Gbps • Packet Forwarding Rate: 8.928 Mpps	• Switching Capacity: 56 Gbps • Packet Forwarding Rate: 41.66 Mpps	• Switching Capacity: 20 Gbps • Packet Forwarding Rate: 14.88 Mpps
Environment	• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: –40˚C to 85˚C (–40˚F to 185˚F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation)	• Operating Temperature: -30 °C to 65 °C (-22 °F to 149°F) • Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation)	• Operating Temperature: 0 °C to 45 °C (0 °F to 113 °F) • Storage Temperature: -40 °C to 85 °C (-40 °F to 185 °F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation)	• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: –40 °C to 85 °C (–40 °F to 185 °F) • Operating Humidity: 5% to 95% (no condensation) • Relative Humidity: 5% to 95% (no condensation)
Certification	EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368-1: 2014+A11: 2017)	EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3- 2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE- LVD (EN 62368-1: 2014+A11: 2017) • Chemistry: CE-RoHS (2011/65/EU)	EMC: • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020) Safety: • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368- 1: 2014+A11: 2017) Chemistry: • WEEE (2012/19/EU), • Reach (Regulation (EC) No.1907/2006), • CE-RoHS (2011/65/EU)	EMC: • FCC (47 CFR Part 15, • Subpart B), • CE-EMC (EN 55032: 2015+A11: 2020, • EN IEC 61000-3-2: 2019, • EN 61000-3-3: 2013+A1: 2019, • EN 50130-4: 2011+A1: 2014, • EN 55035: 2017+A11: 2020), • IC (ICES-003: Issue 7:2020), • RCM (AS/NZS CISPR 32: 2015) Safety: • UL (UL 60950-1), • CB (AMD1:2009, • AMD2:2013, • IEC 62368-1: 2014 (Second Edition), • CE-LVD (EN 62368-1: 2014+A11: 2017) Chemistry: • CE-RoHS (201165EU); • WEEE (201219EU); • Reach (Regulation (EC) No.19072006)
Features	• Model: DS-3E0524-E(B) • Shell: Metal material, fan-free design • Gross Weight: 2.47 kg (5.44 lb) • Installation Mode: Metal material, fan-free design • Surge Protection: 6 kV • MAC Address Table: 8 K • Internal Cache: 4.10 Mbits	• Shell: Metal material, fan-free design • Gross Weight: 0.94 kg (2.07 lb) • Installation Mode: Desk-Mounted,Rail • Surge Protection: 6 kV • MAC Address Table: 2 K • Internal Cache: 1 Mbits Long Range: • Ports 3 to 4: up to 300 m • Long range performance may vary depend on camera model or cable condition. • PoE Watchdog: Ports 1 to 4: auto detect and restart the cameras that do not respond.	• Shell: Metal material • Gross Weight: 1.96 kg (4.32 lb) • Installation Mode: Rack (equipped with mounting ears) • Surge Protection: 6 kV • MAC Address Table: 8 K • Internal Cache: 4.1 Mbits Link Aggregation: • Link aggregation is used to aggregate multiple physical ports to form a logical port for load balancing, bandwidth expansion, and port protection. • Support static link aggregation. • Support 8 aggregation group(s). QoS: • QoS is used to allocate bandwidth to different services so as to provide end-to-end service quality assurance. • Support port-based priority configuration. • Support SP and WRR priority scheduling modes. Loop Prevention: • Loop prevention is used to prevent the switching network from forming loops, which will seriously affect network communication. Disabled by default. • Support 802.1D STP. • Support 802.1w RSTP. VLAN: • VLAN is used for network scale planning and network health improvement. • Support 802.1Q. • Configurable VLAN ID from 1-4094. • Support Trunk, Access port mode. • Support Max. 32 VLAN. DHCP Snooping: • DHCP Snooping can prevent unauthorized connections to DHCP servers from disrupting the network and affecting normal network communication, and only allow • DHCP packets from trusted ports to pass through. Disabled by default.	• Model: DS-3E0510P-E/M • Shell: Metal material • Gross Weight: 1.366 kg (3.01 lb) • Installation Mode: Desk-Mounted,Wall-Mounted • Surge Protection: 6 kV • MAC Address Table: 4 K • Internal Cache: 1.5 Mbits
Dimensions	335.0 mm × 44.5 mm × 175.8 mm (13.2'' × 1.8'' × 6.9'')	158.0 mm × 101.2 mm × 31.6 mm (6.22'' × 3.98'' × 1.24'')	335.00 mm × 44.50 mm × 175.80 mm (13.19'' × 1.75'' × 6.92'')	217.6 mm × 27.8 mm × 108.55 mm (8.6'' × 1.1'' × 4.3'')
Weight	1.60 kg (3.50 lb)	0.38 kg (0.84 lb)	1.12 kg (2.47 lb)	0.635 kg (1.40 lb)
Power	Power Supply: 220 V AC, 50/60 Hz, Max. 0.7 A	• Power Supply: 48 V DC, 1.35 A • Max. Power Consumption: 65 W • Power Consumption in Idle: 5 W	• Power Supply: 220 V AC, 50/60 Hz, Max. 0.3 A • Max. Power Consumption: 12 W • Power Consumption in Idle: 10 W	• Power Supply: 48 V DC, 1.35 A • Max. Power Consumption: 65 W • Power Consumption in Idle: 7 W
